TX3 Molten Salt Triple-offset Butterfly Valve
The Valtek® TX3 Molten Salt triple-offset butterfly valve provides concentrated solar power (CSP) plant operators with reliable performance, tight shut-off and minimized maintenance in molten salt applications.
It can withstand temperatures ranging from 260°C (500°F) to 600°C (1,112°F) in thermal energy storage for industrial processes or power generation. Leakage is eliminated by the design and construction, which includes standard live-loaded Thermiculite or hybrid packing.
... Read more Read less- Superior leakage resistance results from the shutoff design and construction that reliably complies with FCI 70-2 Class V for control valve applications and API 598 for On-Off applications.
- Constant temperatures within the valve stem and packing region are ensured with a comprehensive solution for packing/heat tracing including integrated heating, controls, and sensors
- Reliable packing performance owing to materials and configuration engineered to match the customer’s specific packing load and performance requirements
- Minimized maintenance can be achieved with in-line maintenance (consult Flowserve engineering special
Applicable Standards
- ASME B16.34
- ASME B16.5
- ASME B16.10
- API 609
- FCI 70-2
- API 598
- EN-122661 Rate A
Certificates and Approvals
- Available API 607 and ISO 10497 for fire safe; ISO 15848-1 for fugitive emissions
Temperatures : 260°C to 600°C (500°F to 1,112°F)
Cold salt up to 400°C (752°F) A or SA-216-WCB carbon steel
Hot salt above 400°C (752°F) A or SA-351-CF8C stainless steel
Pressure Range: ASME class 300/600, 150/900/1500 (engineered to order [ETO])
Size Range: NPS 3 to 24 and >24 in. (ETO)
Body style
- Buttweld flanges standard; others engineered to order (ETO)
- Short pattern standard; long pattern available
