- Centerline Supported heavy duty design offers optimum operation under high temperature and pressure.
- Double suction impeller design reduces NPSH required.
- Double volute casing minimizes radial load and shaft deflection.
ISO13709 / API610 (BB2)
Flows to: 3200 m3/h (14080gpm)
Heads to: 470 m (1542 ft)
Pressures to: 44 bar (639 psi)
Temperatures to: 430°C (806°F)
Size Range: 4 to 16 inch
Pressure Class Range: Pressure to 44 bar ( 639psi)
Seating Material:
- S5
- S6
- S8
- C6
- A7
- A8
