- Well suited for high vibration or tight space requirements owing to parallel input shaft and output drive sleeve
- Application versatility provided by available weatherproof and submersible constructions as well as a wide range of output speeds and torques
- Increased uptime facilitated by roller bearing-supported shaft and high-strength gearing, which are rated for extremely high thrust and torque requirements
- High strength and durability provided by ductile iron housing and roller bearing-supported shafts and drive sleeve
- -300C to 900C ambient temperature range
Torque Rating Range: Torque output to 16 984 ft-lb (23 000 Nm)
Thrust Rating Range: Thrust output to 787 000 lb (3500 kN)
Weatherproof
Protected against the ingress of water and dust
Submersible
Suitable for temporary submersion to IP67 and IP68
