- Abrasion and corrosion-resistant high chrome iron concentric casing
- Integrally cast straightening vanes in the suction nozzle
- Closed impeller with pump-out vanes on the front and rear shrouds
- MJ has fluted cutlass rubber bearings
- MJC has restriction bushing
- Directly coupled or V-belt driven
- Hard metal expeller
- Open and recessed impellers
Flowserve
- Flows to 1350 m3/h (6000 gpm)
- Heads to 30 m (100 ft)
- Pressures to 10 bar (150 psi)
- Temperatures to 110°C (225°F)
- Solids from 2% to 70% by weight
- Speeds to 1780 rpm
Size Range:
- Discharge sizes from 65 mm (2.5") to 200 mm (8")
